API Oilfield Solid Control Equipment Poor Boy Degasser, Vertical Mud Gas Separator
Product Details:
| Place of Origin: | China |
| Certification: | API |
| Model Number: | ZYQ Series |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD8000-25000/set |
| Packaging Details: | Export Wooden Case |
| Delivery Time: | 15-30 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 20 sets per month |
|
Detail Information |
|||
| Product Name: | API Oilfield Solid Control Equipment Poor Boy Degasser/Vertical Mud Gas Separator | Keywords: | Poor Boy Degasser / Gas Buster / Mud Gas Separator |
|---|---|---|---|
| Application: | Drilling Mud Solid Control | Working Medium: | Natural Gas, Drilling Fluid(H2S) |
| Weight: | 1500~3500Kg | Capacity: | 200-340 M3/h |
| Highlight: | Poor Boy Mud Gas Separator,Mud Gas Separator API |
||
Product Description
API Oilfield Solid Control Equipment Poor Boy Degasser/Vertical Mud Gas Separator
Poor Boy Degasser / Gas Buster / Mud Gas Separator Descriptions:
Poor boy degasser (Gas Buster or Mud/Gas Separator) is a vertical vessel which is used to remove toxic and hazardous gases from drilling mud that returns from the bore hole. ZYQ series mud gas separator(Poor Boy Degasser) is professional equipment to treat the gas invade mud. When the drilling mud result gas invade, the proportion of its weight and viscosity have a greater deviation not to meet the requirements of drilling. The serious situation is that would cause Chung well, and even blowout accident occurred, if not to treat it timely. ZYQ series Mud gas separator combined with the electric Ignition device can be used to ensure the drilling process smooth. It is devided into the normal pressure mud gas separator and pressure auto-control Mud gas separator, according to the pressure.Mud gas separator is your best choice to prevent drilling mud invasion.
The Advantage of Poor Boy Degasser / Gas Buster / Mud Gas Separator:
1. Material: SS304 or Q345 for body .
2. The whole body: The mud gas separator with the process of the grinding, sand blasting,the 3 layers of painting: epoxy zinc painting as the primer, the epoxy painting as the middle coating, and the polyurethane for the final painting.
3. Separates and discharges the enormous free gas from drilling fluids, including poisonous gases like H2S.
4. Separated gas is carried by discharge lines to a safe area for combustion.
5. The unit is ruggedly built and coated with anti-corrosion epoxy so as to ensure long service life when processing hazardous and toxic gases.
Technical Parameters for ZYQ series Mud/Gas separator:
|
Subject
Model |
Capacity (m3/h ) |
Inlet (mm) |
Outlet (mm) |
Air Discharge Pipe (mm) |
Weight (Kg) |
Dimension (mm) |
| ZYQ-800 | 200~250 | Ø 125(5”) | Ø 200(8”) | Ø 150(6”) |
1500
|
1900×1900×5756 |
| ZYQ-1000 | 200~280 | Ø 125(5”) | Ø 200(8”) | Ø 200(8”) |
2000
|
2000×2000×5960 |
| ZYQ-1200 | 240~300 | Ø 125(5”) | Ø 150(6”) | Ø 200(8”) |
2800
|
2200×2200×6634 |
| ZYQ-1400 | 280~340 | Ø 125(5”) | Ø 250(10”) | Ø 200(8”) | 3500 | 2390×2390×6593 |
Complete soilds control system we supply:
A complete solid control system,including Shale Shaker, Mud Cleaner ,Desander ,Desilter, Centrifuge, Cutting Dryer ,Agitator, Mixing Hopper, Flare Igniter, Various Tanks, Pumps, Degassers etc .
